Arcus

Arcus is the world's first system for continuous glass color monitoring directly on the line.Arcus allows you to reduce glass color analysis time to zero, eliminating sampling analysis on containers taken by an operator from the production line.By performing measurements directly on the line and automatically, the color sampling time by the operator is eliminated, dangerous sample cutting activities are removed, and data entry errors by the operator are eliminated.Arcus allows for the replacement of traditional SPC (Statistical Process Control) color control activities with an automatic and error-free tool in a faster and safer way.HighlightsFast recipe creation (10 minutes)Eliminated color sampling timesReal-time glass color controlReal-time color deviation analysisData generation for Industry 4.0

Extrema

Extrema is a system for monitoring the bottoms of glass containers based on artificial intelligence.Extrema performs analyses with multiple recipes and different types of controls optimized for the various areas of the container's bottom, simplifying the calibration phase for the operator. The system is available in two versions with 5 control stations (1800 mm in line length) and in a SLIM version with 2 control stations (950 mm in line length).Other highlighted featuresQuick recipe creation (10 minutes)Analysis system based on artificial intelligenceAnalysis of containers up to 600 mm in heightData generation for Industry 4.0Optional Finish kit

Kit Finish

The Finish Kit can be installed on the Omnia, Linea, and Extrema systems and allows for the addition of quality control functionality for the Finish.The LED lighting system has been specifically designed to highlight all types of defects.Thanks to the high-resolution acquisition system and the developed control software, we can achieve identifications close to 100%.

Finish

Libra A20

Libra A20 is an innovative real-time online machine vision system developed to check:fill levelcap presencecap insertion compliance.Libra A20 is equipped with a high-resolution vision system and an embedded processing unit that performs all checks at a maximum speed of 80,000 containers/hour.Highlighted featuresFast return on investmentPortable systemSystem for food environmentsData generation for Industry 4.0 architectures

Vision

Linea

Linea is the innovative intelligent system for detecting shoulder cuts on standard and shaped bottles, requiring no adjustment of alignments and easily managing shaped formats without touching the container.Linea automatically detects the defect the first time it appears during inspection without the need for adjustments between emitter and receiver; setup is reduced to selecting an area with the mouse and defining the minimum defect size. Linea ensures 100% product inspection by eliminating the need to reselect items in case of new types of cuts.Highlighted FeaturesQuick recipe creation (10 minutes)Container analysis with heights up to 600 mmManagement of shaped formatsNo emitter/receiver alignmentData generation for Industry 4.0Optional Finish KitThe Finish Kit system for quality control of the container’s neck can be integrated with Linea.

Linea SBI

SBI Line is the portable wheeled system for defect inspection at the opening of containers.The non-contact system allows for quick and easy inspection of standard and shaped containers.Machine setup is reduced to defining the height of the container, selecting areas of interest with the mouse, and defining the minimum defect size.Highlighted FeaturesQuick recipe creation (10 minutes)Portable wheeled systemAnalysis of containers up to 600 mm in heightData generation for Industry 4.0

Multioculus

Multioculus is an innovative control system made up of multiple intelligent vision devices, Oculus, designed for non-contact research of cuts on containers in the neck area or in other areas of the container.Key FeaturesQuick recipe creation (10 minutes)Versatile mechanical configuration of vision systemsData generation for Industry 4.0

Oculus

Oculus is an embedded vision system for upgrading carousel machines that allows for the replacement of traditional aiming with an advanced analysis system.The specially designed micro-camera to be easily integrated within existing control systems in the plant aims to maximize control performance.Oculus indeed consists of only a micro-camera with a server and an illuminator that projects light onto the container and has two operating modes:reflectionblockingOne mode has already been tested and is currently in use on major carousel machines of both old and new generationHighlighted FeaturesQuick recipe creation (10 minutes)Web-based user interfacePortable systemInstallable on carousel machinesData generation for Industry 4.0

Omnia

Omnia is the revolutionary control system that brings three unique innovations to the sector:multi-format management for up to 10 items simultaneously.acquisition and analysis of color images (the first in its category)Artificial Intelligence engine.Artificial intelligence is the revolutionary technology that characterizes our time; mimicking the structure of the human brain, it allows the system to “intelligently” intercept defects: Omnia sees, reasons, and learns directly on the production line. Video Systems has been employing this technology in its systems since 2003 and relies on a defect database of over 15 years.Omnia provides remarkable results compared to traditional control systems with significant advantages for the customer:reliability of resultsreduction of costs and machine setup timesdrastic reduction of false rejects by optimizing all control parameters automatically.Since 2003, Omnia has been continuously improved to enhance its control performance. Today, Omnia 2017 is available in 3 basic configurations that vary in the number and types of cameras:Configuration with 13 monochrome or color camerasConfiguration with 20 monochrome or color camerasConfiguration with 32 monochrome or color camerasHighlighted featuresQuick recipe creation (10 minutes)AI-based analysis systemContainers up to 600 mm in heightDynamic adjustment of lighting based on the glass density of the itemInterfacing with Vertech.Item line selectorData generation for Industry 4.0Optional Finish KitThis is a smart way to conceive quality control.The uniqueness of Omnia has been recognized since its early days in 2003 and has received significant awards, including one from the Italian Government, which selected it as one of the 265 innovations (out of 3000 candidates) that can bear the title “Italy of Innovators” and represent Italian technological excellence. www.italiainnovatori.gov.it/omniaelinea.

Omnia

Proximus

Proximus is the first vision system for counting and monitoring jammed products directly at the mold exit:checks for any jams at the mold exit (often caused by bottles stuck together)counts the number of containers that passed through and indicates those to be discarded.In this way, Proximus allows for immediate identification of defective containers, evaluating the actual production against the waste generated.A ejector can be paired with Proximus to automate the elimination of waste.Other highlighted features:– Data generation for Industry 4.0 architectures

Versus

Versus is a recognition and selection system for items on production lines equipped with self-learning of container shape.Compared to standard sensors used for single-point selection, Versus uses the bottle profile to always select the correct product.Versus is equipped with remote calibration software with the possibility of connection to mobile systems, which allows for the verification of parameters and the operation of the system along the entire line directly in the selection area.Key FeaturesReduction of setup timesSelf-learning container profileReal-time monitoring of production statisticsAutomatic management of white and colored containersElimination of rejects from the production lineData generation for Industry 4.0

Vertigo

Vertigo is a system for the sampling verification of laboratory containers that can be directly installed on production lines (cold-end) and in the hot zone (hot-end) that verifies: diameter measurement and calibrationdeviation of container verticalitydeviation of crooked neckovalization of containerflatness of the label areaThe container under verification is manually placed by the operator on the designated rotating platform, and the system executes all checks (non-contact) in 10 seconds, sending the data directly to control software or company databases, effectively eliminating errors in mechanical positioning of probes, data entry errors, and ensuring repeatability of measurements over time.Vertigo allows traditional SPC (Statistical Process Control) dimensional control activities to be replaced with an automatic and error-free tool in a faster and safer manner.Highlighted FeaturesFast manual recipe creation (2 minutes)Direct receipt of recipes from the remote Vertech systemReduction of measurement times (10 seconds for all measurements)Data generation for Industry 4.0

VIP LINE (Vision Inspection for Packaging codes)

VIP LINE is born from the collaboration between Video Systems and GISAL with the aim of providing the market with a valid and reliable solution for quality control and traceability of codes applied on beverage products, particularly for the traceability of Federal Marks on alcoholic beverages adopted in the EGAIS system.VIP LINE is a solution based on 4 main systems:VIP-LABELPerforms non-contact inline reading of codes present on the body and cap of the product, allowing the aggregation of codes to the product in transit.The acquired data is sent directly to the VIP-TRACK system for subsequent use.VIP-BOXPerforms non-contact inline reading of codes on the caps of canned bottles and the box code, allowing aggregation of bottles and boxes.The acquired data is sent directly to the VIP-TRACK system for subsequent use.VIP-PALLETPerforms non-contact inline reading of box codes and pallet codes, allowing aggregation of boxes and pallets.The acquired data is sent directly to the VIP-TRACK system for subsequent use.VIP-TRACKIs the aggregation software installed on the appropriate ServerDB server for managing and tracking codes from production to market entry. The system can manage not only automatic units but also manual devices for data creation and aggregation by operators located along the production lines. In addition to the main elements, accessories are also available such as:manual readersprintersbottle spacersinline ejectors
